Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
| Jumlah stasiun: | 45 (GZPK-45) / 55 (GZPK-55) | Standar perkakas: | D (GZPK-45) / B (GZPK-55) |
|---|---|---|---|
| Tekanan utama Max: | 100 kN | Max Pra-Tekanan: | 20 kN |
| Diameter Tablet Maks (Bulat): | 25 mm (L) / 18 mm (B) | Diameter Tablet Maks (Tidak Beraturan): | 25 mm (L) / 19 mm (B) |
| Kedalaman pengisian maksimal: | 20 mm (L) / 18 mm (B) | Ketebalan tablet maks: | 8 mm (D) / 7 mm (B) |
| Kecepatan Max Turret: | 70 r/mnt | Kapasitas produksi maksimal: | 378.000 (GZPK-45) / 462.000 (GZPK-55) buah/jam |
| Tenaga Motorik: | 11kW | Ukuran Keseluruhan: | 1530x1250x1900mm |
| Berat mesin: | 4.300kg | Kompatibilitas Bentuk Tablet: | Bulat, Tidak Beraturan, Terukir Dua Sisi |
| Sistem Pengendalian: | PLC dengan layar sentuh HMI | Pelumasan: | Sistem Oli & Gemuk Sentral Otomatis |
| Menyoroti: | high speed tablet press machine,automatic tablet weight control,GMP rotary tablet compression |
||
The TIANHE GZPK-45 and GZPK-55 represent the pinnacle of speed tablet press machine engineering for mid-to-large tablet production. As a double-sided rotary tablet press equipped with automatic tablet weight control and intelligent rejection systems, this machine delivers unmatched precision and throughput for pharmaceutical, nutraceutical, chemical, and food-grade tablet manufacturing operations. Engineered with D-type and B-type international tooling standards respectively,
